Total_station Nikon 2M Plus With Reflektorless

Kategori:

Deskripsi

Total Station Nikon Nivo 2.M 2-Second Reflectorless adalah Total Station dengan optik plummet dan tanpa henti menampilkan fitur optik kejelasan Nikon yang legendaris untuk gambar yang lebih jelas dalam kondisi cahaya terang dan rendah. Dengan perangkat lunak Nikon Survey on-board, instrumen optik ini menyediakan surveyor dengan alat pemosisian yang berharga untuk melakukan pengumpulan data topografi, pekerjaan pengintaian dan tata letak. Ini juga memiliki kemampuan Bluetooth untuk menghubungkan ke kolektor data dan memori internal yang besar untuk menyimpan file.

Features Total Station Nikon Nivo 2M Reflectorless

Specifications Total Station Nikon Nivo 2M Reflectorless

General
Weight 8.4 lbs (3.8 kg)
Dimensions 5.8 in x 5.7 in x 12.0 in (14.7 cm x 14.4 cm x 30.4)
Warranty 1-year
Protection Class IP66 (protected against dust and strong water jets)
Tripod Thread 5/8 – 11
Internal Memory 10,000 points
Software Nikon Survey
Tribrach Detachable
Guide Light Red LED
Angle Measurement
Measuring Method/Reading System Absolute encoder
Minimum Reading 1-second/5-second/10-second
Accuracy 2-second
Diameter of Circle 2.4 in (6 cm)
Distance Measurement
Unit of Measure (distance display) m/ft
EDM Accuracy (Precision) ±(2mm + 2ppm x D) for prism; ±(3mm + 2ppm x D) for no prism
Minimum Reading 500 m (1,640 ft)
Tilt Sensor/Compensator
Range ±3.5
Type Liquid
Method Electronic Automatic
Battery/Power
Power Source Two rechargeable Li-Ion batteries
Battery Life 62 hours
Battery Life Alert yes
Voltage 3.8 V DC
Optical Plummet
Image Erect
Magnification 3×
Field of View 5 degrees
Focus Range 0.5 m (1.6 ft) to infinity
Level
Circular Bubble Vial 10 minutes per division/(2 mm)
Electronic Level Displayed on the LCD
Telescope
Length of Tube 125 mm (4.9 in)
Image Erect
Diameter of Objective Lens (Aperture) 45 mm EDM (1.8 in)
Magnification 30x
Field of View 1 degree 20 arcmin
Resolving Power 3 arcsec
Minimum Focus Distance 1.5 m (4.9 ft)
Reflectorless yes
Display and Keypad
Type Black and white LCD
Sides Dual
Keys Alphanumeric
Backlight yes
Pixels 128 x 64 pixels
Temperature
Operating -4°F~122°F (-20°C~50°C)
Storage -13°F~140°F (-25°C~60°C)
Applications
Surveying and Construction yes
Mapping and GIS (geographic information systems) yes
Utilities yes
Environment Studies yes
Geomarking yes
Archaeology yes
Accident Reconstruction yes
Measurement Range (under fair weather conditions)
Single Prism 3,000 m (9,843 ft)
No Prism 500 m (1,640 ft)
Reflector Sheet 270 m (886 ft)
Functions
Coordinate Measurement Point yes
Angle and Distance Stake Out yes
Stake Out Line yes
Offsets yes
Missing Line yes
Remote Elevation yes
Resection yes
Area Calculation yes
Laser Plummet
Class 2
Wavelength 635 nm
Interface
Bluetooth Class 2
Pin Port RS-232C

What’s in the Box

Beli Total Station Nikon Nivo 2M Plus dengan harga ekonomis Gratis biaya pengiriman wilayah Tangerang dan dapat dikirim keseluruh Indonesia. Dapatkan hanya di toko online transsurvey.id belanja online mudah dan aman.
