Specifications
Laser
Color Red
Wavelength 635 nm
Classification Class 3R
Direction Horizontal and vertical
Visibility Visible
Range
Interior N/A
Exterior Up to 2,624 feet (800 m)
Self Leveling ±5 degrees
Remote N/A
Battery/Power
Battery Life with Rechargeable Battery Pack Up to 65 hours
Battery Life with Alkaline Batteries Up to 120 hours
Power Source Rechargeable NiMH or D-cell
Battery Life Alert Yes
Features
Automatic Shut-Off N/A
Display Backlit, graphic LCD
Drop Damage Protection N/A
Bump Sensor (H.I./Out of Position Alert) Yes
Protection Class IP66 dustproof and powerful water jet resistant
Tripod Adapter (Center Screw Thread) 5/8 x 11
Removable Laser Cage (for exact beam spotting) N/A
Detecting Indicator N/A
Dual Handles Yes
Built-in Bubble Vial Yes
Adjustable Rotating Speed 300, 600 RPM
One-Touch Commands N/A
Wall Mount Bracket N/A
Plumb Point N/A
General
Maximum Power Output N/A
Weight 5.95 lbs (2.7 kg)
Dimensions 7.0″ L × 7.7″ W × 8.5″ H
Warranty 5-year
Remote Control Operating Distance Up to 328 feet (99.97 m)
Extra Technology
Remote Control RC-60 (Optional)
Detector/Receiver LS-80L or LS-100D
Smart Scan® N/A
Smart Slope® N/A
Accuracy
Horizontal Horizontal ±10 arc seconds
Vertical N/A
Temperature
Storage -22 to 140 °F (-30 to 60 °C)
Operating -4 to 122 °F (-20 to 50 °C)
Charger
Input N/A
Output N/A
Charging Time Up to13 hours
Functions
Slope Match N/A
Grade Operation Automatic
Automatic Leveling Yes
Beam Operating Modes Beam masking
Scanning Modes N/A
Applications
Checking/Setting Elevations Yes
Transferring Points from Floor to Ceiling N/A
Machine Control of Excavators, Graders, Dozers or Similar Equipment N/A
Installation of Interior Fittings (cabinets, lighting, windows, countertops, etc.) Yes
Short-Range Leveling for Decks, Patios & Swimming Pools Yes
Installation/Leveling Interior Walls Yes
Installation/Leveling Ceiling Grids Yes
Squaring and Layout of Partitions, Walls & Tile Floors N/A
Concrete Forms, Footings and Foundations Yes
Plumb Reference N/A
Checking Elevations of Sub-Base and Sub-Grade Yes
Short-Run Vertical Alignment Yes
Checking Building Square & Area N/A
Estimating Cut & Fill Yes
Matching Existing Slope & Grade Yes
Locating Finished Floor Levels Yes
Grade
Type Dual
Percentage ±15%
