Deskripsi
GNSS Performance (1)
Channels 336 channels
GPS L1C, L1C/A, L2E, L2C, L5
GLONASS L1C/A, L2 C/A, L3 CDMA
Galileo E1, E5a, E5b, E5AltBOC, E6
BeiDou B1, B2, B3
SBAS L1C/A, L5
QZSS L1 C/A, L1 SAIF, L2C, L5, LEX
IRNSS L5
L-BAND RTX
GNSS Accuracies (2)
Real time
kinematics (RTK)
Horizontal: 8 mm + 1 ppm RMS
Vertical: 15 mm + 1 ppm RMS
Initialization time: < 10 s
Initialization reliability: > 99.9%
Post-processing
kinematics (PPK)
Horizontal: 2.5 mm + 1 ppm RMS
Vertical: 5 mm + 1 ppm RMS
Post-processing
static
Horizontal: 2.5 mm + 0.5 ppm RMS
Vertical: 5 mm + 0.5 ppm RMS
Code differential Horizontal: 0.25 m RMS
Autonomous Horizontal: 1 m RMS
Vertical: 1.5 m RMS
Positioning rate Up to 50 Hz
Time to first fix (3)
Cold start: < 45 s
Hot start: < 10 s
Signal re-acquisition: < 1 s
RTK tilt -compensated Additional horizontal pole-tilt uncertainty
typically less than 10 mm + 0.7 mm/ tilt
Hardware
Size ( L x W x H ) 159 mm x 150 mm x 110 mm
(6.3 in 5.9 in 4.3 in)
Weight 1.26 kg (2.77 lb)
Environment
Operating: -40 C to +65 C
(-40 F to +149 F)
Storage: -40 C to +85 C
(-40 F to +185 F)
Humidity 100%
Ingress protection IP67 waterproof and dustproof, protected
from temporary immersion to depth of 1 m
Shock Survive a 2-meter pole drop
Tilt sensor
Calibration-free IMU for pole-tilt
compensation.
Immune to magnetic disturbances.
EBubble leveling
Front panel 4 status LED
1.46” OLED Display
Certifications
FCC Part 15 (class B Device), FCC Part 22, 24, 90; CE Mark;
NGS Antenna Calibration; MIL STD 810G,Method 514.7
Communication
Network modem
Integrated 4G modem
LTE (FDD): B1,B2,B3,B4,B5,B7,B8,B20
DC-HSPA+/HSPA+/HSPA/UMTS:
B1, B2, B5, B8
EDGE/GPRS/GSM
850/900/1800/1900MHz
Wi-Fi 802.11 b/g/n, access point mode
Bluetooth v4.1
Ports
1 x 7-pin LEMO port (external power, RS-
232)
1 x USB Type-C port (data download,
firmware update)
1 x UHF antenna port (TNC female)
UHF radio
Standard Internal Rx/Tx: 410 – 470 MHz
Transmit Power: 0.5 W to 2 W
Protocol: CHC, Transparent, TT450,
SATEL3AS
Link rate: 9600 bps to 19200 bps
Range: 5 km under optimal conditions
Data formats
RTCM 2.x, RTCM 3.x, CMR, CMR+,
SCMRX input and output
HCN, HRC, RINEX 2.11, 3.02
NMEA 0183 output
NTRIP Client, NTRIP Caster
Data storage 32 GB internal memory
Electrical
Power consumption 5 W (depending on user settings)
Li-ion battery capacity 2 x 3400 mAh, 7.4 V
Operating time on
internal battery (4)
UHF receive/transmit (0.5 W): 5 h to 8 h
Cellular receive only: up to 9 h
Static: up to 10 h
External power input 9 V DC to 28 V DC
