Deskripsi
System Performance
Absolute accuracy1 in [X,Y], [Z] No GNSS outage 60 sec GNSS
outage
Post-processing 11mm, 11mm 14mm, 16mm
RTK 12mm, 12mm
Scanner TRK500 Neo TRK700 Neo
Effective measurement rate 500kHz 1000kHz
Scan speed Up to 250Hz Up to 500Hz
Maximum range 50% reflectivity at
200kHz / 500kHz 490m / 250m
Maximum range 10% reflectivity at
200kHz / 500kHz 205m / 130m
Number of returns Up to 4
Minimum range 1.5m
Field-of-view 360° full circle
Laser class Class 1, eye safe
Camera
Maximum system resolution 120MP powered by SmartFuse technology
Type 360° Panorama Butterfly Side Pavement Front
Resolution 24MP 48MP 24MP 24MP
Mounting Fixed Flexible; Hz & V Fixed Fixed
Focal length 3.3mm 12.45mm 12.45mm 12.45mm
Calibration Permanent Self-calibrating Self-calibrating Self-calibrating
Capture mode By distance at maximum 8 fps
Anonymisation Natively AI based, real-time blurring; fully compliant to GDPR
Colour calibration According to CIEDE2000
Brightness control Real-time, fully automatic
Positioning
GNSS 555 channel, multi-constellation, multi-frequency
Antenna Fully integrated, with additional second antenna support
SLAM Dual SLAM scanner integration for optimised position in challenging conditions
DMI Supported – see “Accessories” section
RTK HxGN SmartNet / NTRIP networks
Remote Services
Theft deterrence² Built-in LOC8 theft deterrence and location solution for remote tracking, localisation
and locking by mobile phone or computer
Support Remote in-field support access
Power Supply
Type Vehicle independent
Hot-swappable, up to 3 x Li-Ion Pegasus battery units
Interface Ruggedised, IP54, industrial grade, 2.4 inch colour LCD displaying real-time battery
health monitoring
TRK500 Neo TRK700 Neo
Operating time 7h / battery unit 6h / battery unit
Transport Transportation mode for ground and aircraft shipping
Fully compliant to dangerous goods UN 3480/3481
Control Unit
Type Ruggedised, IP54, industrial grade, multi-core PC with built-in machine
learning chip
Interface 5.0 inch colour and touch LCD displaying live battery health monitoring
Real-time capabilities Data pre-processing and AI based tasks
Data storage 2 x 2TB or 2 x 3.8TB, real-time data stream to high performance, removable SSD`s
Environmental
characteristics
Maximum speed 130km / h
Temperature range operating -10°C to +50°C
Temperature range storage -20°C to +50°C
IP rating IP67 during operation, fully dust tight and withstands temporary immersion
under water
Shock and vibration Withstands 4g shocks, ISO9022, MIL-STD-810H
Dimensions TRK500 Neo TRK700 Neo
Dimensions [L/W/H] 70 / 33 / 56cm 72 / 46 / 56cm
Weight 18 kg 23 kg
Mounting Rotational-tilt mount, adjustable in horizontal position -30°, 0°, +30°, tilting up to 45°
improving accessibility and ergonomics by reducing 36cm the mounting height
Beli Leica Pegasus TRK 500/700 NEO, dengan harga ekonomis Gratis biaya pengiriman wilayah Tangerang dan dapat dikirim keseluruh Indonesia. Dapatkan hanya di toko online transsurvey.id belanja online mudah dan aman.
